1. 低烟无卤、阻燃材料,抗拉保护,低碳无毒,安全环保。
2. 精密陶瓷插芯,性能稳定,耐插拔次数高。
3. 插入损耗低,传输更加稳定。
4. 良好的互换性的重复性。
5. 满足-40~85℃工环境,性能稳定。
1. CATV
2. 局性域网、接入网
3. 电信网络、Gigabit数据网络
4. 测试、医疗设备
5. 其他工业及军事应用
技术规范
Items |
Description |
Connector Type |
FC, SC, ST, MU, LC, E2000, /UPC,APC |
Fiber Count |
4, 6, 8, 12 & 24 Fiber |
Fiber Mode |
Single mode: OS2 9/125µm Multimode: OM4 50/125µm, OM3 50/125µm |
Branch Diameter |
Φ2.0mm ,φ3.0mm |
光学性能(LC/SC/FC/ST/MU/SMA)
Type
Unit
Description
Model
--
SM
MM
Polish
(dB)
UPC
APC
UPC
PC
Insertion Loss
(dB)
≤0.3
≤0.3
≤0.3
≤0.3
Return Loss
(dB)
≥50
≥60
≥30
--
Cable Diameter
--
Φ3.0,Φ2.0,Φ0.9
端面几何参数
Type |
Unit |
Description |
|||
PC |
APC |
||||
SC |
MU/LC |
SC |
MU/LC |
||
Radius of curvature |
(mm) |
10 - 25 |
7-25 |
5-12 |
|
Fiber Height |
(nm) |
-100 - +50 |
-100 - +50 |
||
Apex offset |
(nm) |
Max 50 |
Max 50 |
||
Angle(Degree) |
(°) |
-- |
8±0.5 |
