Fiber

Count

Dimension

(MM)

Weight

(kg/km)

Tensile (N)

LongTerm/Short Term

Crush(N/100mm)

LongTerm/Short Term

Min.Bend Radius(mm)

Dynamic / Static

Temperature (°C)

2

7.0

45

200

400

500

1000

20D

10D

-20～+70

       Note:  1. All the values in the table, which are for reference only, are subject to change without notice;

     2. Dis outer diameter of the round cable;

     3.The minimum bend radius (static) is 5D when G.657 fiber is used.
