Fiber

Count

Dimension

(MM)

Weight

(kg/km)

Tensile (N)

LongTerm/Short Term

Crush(N/100mm)

LongTerm/Short Term

Min.Bend Radius(mm)

Dynamic / Static

Temperature (°C)

1

3.0×2.0

12

40/100

80/200

500/1000

1000/2200

60

30

-20～+70

2

3.0×2.0

12

40/100

80/200

500/1000

1000/2200

60

30

-40～+70

Note: 1. All the values in the table, which are for reference only, are subject to change without notice;

 2.The cable core use the colored coating fiber of 250um;

 3.The tensile and crush of the cable are accordance with the value in the table when the strength member of FRP/ are used;

 4.The minimum bend radius (static) is 15mm when G.657 fiber is used.
