1. 低插入损耗
2. 宽频带
3. 高通道隔离
4. 高稳定性和可靠性
1. 频道添加/删除
2. DWDM网络
3. 光纤放大器
性能指标
Parameter
4 Channel
8 Channel
16 Channel
32 Channel
40 Channel
Channel Wavelength(nm)
ITU-T Grid
Channel Spacing (GHz) GHz)
100G/200G
Insertion Loss(dB)
≤1.6
≤2.6
≤3.8
≤4.6
≤5.0
Channel Ripple(dB)
0.3
Isolation(dB)
Adjacent
>25
Isolation(dB)
Non-adjacent
>40
Insertion Loss Temperature Sensitivity(dB/℃)
≤0.005
Wavelength Temperature Shifting(nm/℃)
<0.002
Polarization Dependent Loss(dB)
<0.1
Polarization Mode Dispersion(PS)
<0.1
Directivity(dB)
>50
Return Loss(dB)
>45
Maximum Power Handling(mW)
500
Operating Temperature(℃)
-10~80
Storage Temperature ℃)
-40~85
dimension (mm) (ABS or Aluminium)
1.L100 x W80 x H10 ( 2 CH~8CH Module) 2.L120xW80xH18 (9 CH~16CH Module)
3. L140xW115xH18 (>16CH Module)
Above specification are for device without connector
订单信息
Channel Spacing
Channel Wavelength
Fiber type
Pigtail Type
Fiber length
Connector
50=50G
100=100G
200=200G
O:1260~1360nm
E+S:1360~1530nm
C:1530~1565nm
L:1565~1625
C20= 1561.42 nm
1-G652D
2-G657A
3-Other
A—Bare fiber
B—900um loose tube
C—900um tight tube
D—2.0mm loose tube
E—3.0mm loose tube
00—Other
05—0.5m
10—1m
15—1.5m
20—2 m
1—FC/UPC
2—FC/APC
3—SC/UPC
4—SC/APC
5—LC/UPC
6—LC/APC
7—Other
……
