1、强度高、弯曲性好,不含油膏,易于施工和接续。可分别包含单模和多模光纤,便于特殊场合的使用。
2、高低温稳定特性。
1、室内水平线,垂直布线,室外布线直接引入室内,降低成本。
2、通信设备尾缆及活动连接线、跳线。
Fiber
Count
Dimension
(MM)
Weight
(kg/km)
Tensile (N)
LongTerm/Short Term
Crush(N/100mm)
LongTerm/Short Term
Min.Bend Radius(mm)
Dynamic / Static
Temperature (°C)
2
2.8x4.8
13.1
100
200
300
1000
60
30
-20~+70
2
3.0x5.0
14.8
100
200
300
1000
60
30
-20~+70
2
4.0x7.0
25.6
160
300
300
1000
80
40
-20~+70
Note: 1. All the values in the table, which are for reference only, are subject to change without notice;
2. The minimum bend radius (static) is 15mm when G.657 fiber is used.
