1、非金属加强、油膏填充、松套层绞。
2、抗张元件为高弹性模量的芳纶纱。
3、缆径小、重量轻、跨距可达1500m对塔的附加负载低、抗拉强度大绝缘性能好、防雷电、芳纶纱受力均匀,具有极优的应力应变能力。
4、抗放电腐蚀性能最佳、可适应恶劣的气候条件、可不停电施工,电力线路故障不影响光缆的正常传输。
5、具有良好的抗紫外辐射性能。
1、适合多雷区及电磁干扰严重场所布线。
2、适合架空。
3、长途通信、局间通信。
Fiber
Count
Span(m)
Diameter
(mm)
Module
(N/mm²)
Linear Expanding
Coefficient(1/K)
Weight
(Kg/km)
Safely running strain
(N)
Weather condition: 35m/s wind speed and 0mm ice thickness
24
800
15.5
2.86x10^4
0.02x10^-6
200
29680
Weather condition: 10m/s wind speed and 5mm ice thickness
24
800
14.5
2.33x10^4
0.02x10^-6
185
19600
Note: All the values in the table, which are for reference only, are subject to change without notice.
