1. 采用标准的高精度MPO/MTP光纤活动连接器;
2. 100%工厂预端接并测试,保证其传输性能;
3. 牵引拉手可选择配置,现场施工便利;
4. 可快速配置与组网,减少现场安装时间;
5. 快速升级,支持并行传输系统应用;
6. 符合IEC61754-7;
7. 符合IEC61754-7,TIAFOCIS 5/604-5,GR-143的标准。
1. 数据中心;
2. 局域网/广域网用户端;
3. 架体内部配线,区域配线区至设备区的线路连接。
技术规范(MPO/MTP)
Items |
Description |
|
Connector |
MPO(MTP) |
LC |
Connector Type |
Female / Male |
UPC / APC |
Connector color |
OS2: Green OM4/OM3: Aqua |
OS2: UPC-Blue ,APC-Green OM4/OM3: Aqua |
Fiber Count |
4~72 Fibers |
|
Fiber Mode |
Single mode: OS2 9/125µm Multimode: OM4 50/125µm, OM3 50/125µm |
|
Fiber Brand |
Corning ClearCurve ® multimode fiber and SMF-28® Ultra optical fiber |
光学性能(LC/SC/FC/ST/MU)
Type |
Unit |
Description |
|||
Model |
-- |
SM |
MM |
||
Polish |
(dB) |
UPC |
APC |
UPC |
PC |
Insertion Loss |
(dB) |
≤0.3 |
≤0.3 |
≤0.3 |
≤0.3 |
Return Loss |
(dB) |
≥50 |
≥60 |
≥30 |
-- |
Cable Diameter |
-- |
Φ3.0,Φ2.0,Φ0.9 |
