Fiber Count |
Dimension (MM) |
Weight (kg/km) |
Tensile (N) Long Term/Short Term |
Crush(N/100mm) Long Term/Short Term |
Min.Bend Radius(mm) Dynamic / Static |
Temperature (°C) |
|||
1 |
5.2×2.0 |
18 |
300 |
600 |
1000 |
2200 |
60 |
30 |
-20~+70 |
2 |
5.2×2.0 |
18 |
300 |
600 |
1000 |
2200 |
60 |
30 |
-20~+70 |
Note: 1. All the values in the table, which are for reference only, are subject to change without notice; 2.The tensile and crush of the cable are accordance with the value in the table when the strength member of FRP are used; 3.The minimum bend radius (static) is 15mm when G.657 fiber is used. |
