Parameter

Specification

Wavelength

C21~C36/C45~60

Channel Spacing

100GHz (0.8nm)

Channel Passband

±0.11nm

Technology

TFF(Thin Film Filter)

Insertion Loss

≤4.0dB

Center Wavelength Accuracy

±0.05nm

Return Loss

≥45dB

Directivity

≥45dB

Polarization Mode Dispersion

≤0.1ps

Polarization Dependent Loss

≤0.3dB

Channel Isolation

Adjacent ≥30dB  Non-adjacent≥45dB

Operating -20 to 70°C Storage -40 to 85°C

Net Weight

3.5KG

Dimensions (HxWxD)

44*440*230mm

Product No.

Product description

DM32-1U01-C2160-RB-A

DWDM MUX DEMUX 16CH 32Waves (RX C21~C36/ TX C45~C60), With

R/B Port Single fiber in Side A

DD32-1U01-C2160-RB-B

DWDM MUX DEMUX 16CH 32Waves (RX C45~C60/ TX C21~C36), With

R/B Port Single fiber in Side B
